Asus PRIME H610M-A WIFI DDR5 Intel Motherboard

Product Description

Specification:   Brand ASUS Model H610M-A CPU Socket Type LGA1700 CPU Type 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supported CPU Technologies Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** Chipset Intel H610 Express Chipset Number of Memory Slots 2 x DIMM, Maximum Memory Supported 96GB Channel Supported Dual channel memory architecture PCIe 3.0 x 1 1 PCIe 3.0 x1 Additional RAID Controller 4 x SATA 6Gb/s connectors Audio Chipset Realtek 7.1 Surround Sound High Definition Audio CODEC LAN Chipset ASUS LANGuard Max LAN Speed 1 x Intel® 1Gb Ethernet USB Rear USB (Total 5 ports) :1 x USB 3.2 Gen 2 (10G) port (1 x Type-A),4 x USB 2.0 ports (4 x Type-A) ; Front USB (Total 6 ports) : 1 x USB 3.2 Gen 1 (5G) connector (supports USB Type-C®) 1 x USB 3.2 S/PDIF Out 1 x S/PDIF out header(s) Audio Ports 3 x audio jacks PS/2 1xPS/2 keyboard (purple)/PS/2 mouse (green) HDMI 1 x HDMI Onboard USB 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) Form Factor mATX Form Factor 9.6 inch x 8.5 inch ( 24.4 cm x 21.6 cm ) Power Pin 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector
