TP Link VIGI InSight S345

Model: tp-link-s345

Key Features

• Model Name: VIGI InSight S345 (often listed with lens options, e.g., S345(2.8MM), S345(4MM), or S345(6MM)) Camera Resolution: 4MP (Max. Resolution: 2688 x 1520 pixels) Image Sensor: 1/2.7” Progressive Scan CMOS Lens: Fixed Focal Lens (Available in 2.8 mm, 4 mm, or 6 mm focal length options), F1.6 aperture. 2.8 mm FOV: Horizontal: 100°, Vertical: 54°, Diagonal: 118° (Wider coverage) 4 mm FOV: Horizontal: 80.4°, Vertical: 41.8°, Diagonal: 98.7° (Standard view) 6 mm FOV: Horizontal: 52.7°, Vertical: 29°, Diagonal: 60.8° (More focused/telephoto view) Night Vision: Features both IR LEDs (30m range) and White LEDs (30m range). The white LEDs enable 24-hour full-color imaging even in very low light conditions (down to 0 Lux with illuminators), providing more detailed and informative footage than traditional black and white night vision. Video Compression: H.265+/H.265/H.264+/H.264, providing highly efficient storage and bandwidth usage, significantly reducing storage requirements. Audio: Built-in microphone (records within approximately a 16.4-ft / 5m radius) and built-in speaker for two-way audio communication, allowing you to listen in and speak through the camera. Storage: Supports local storage via a MicroSD card slot (up to 512 GB, card not included). Connectivity: Wired Ethernet (1 RJ45 10/100M Self-Adaptive Ethernet Port) with Power over Ethernet (PoE) support (802.3af/at), simplifying installation as it carries both power and data over a single cable. Durability: IP67 weatherproof rating (resistant to dust and water immersion) and IK10 vandal-proof rating (resistant to significant impact), making it suitable for harsh outdoor environments. Form Factor: Bullet style, suitable for wall or ceiling mounting. Manual angle adjustment range: Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°. Smart Detection (Deep Learning Functions): Advanced intelligent features for accurate alerts and efficient searching: People & Vehicle Analytics: Classifies humans and vehicles, significantly reducing false alarms triggered by irrelevant motion (e.g., swaying trees, animals, shadows) and making post-event searches faster. Intrusion Detection, Line-Crossing Detection, Region Entering/Exiting Detection, Object Abandoned/Removal Detection, Loitering Detection, Abnormal Sound Detection, Scene Change Detection, Motion Detection (enhanced with Human & Vehicle Classification), Camera Tampering Detection. Active Defense: Can trigger audible warnings (via built-in speaker) and white light flashing to actively deter intruders in real-time. Supports user-created custom voice audio for warnings. Image Enhancement: True WDR (120dB) for balanced images in high-contrast lighting, 3D DNR (Digital Noise Reduction), BLC (Backlight Compensation), HLC (Highlight Compensation), Smart IR. Management: Can be managed via TP-Link's VIGI App, VIGI Security Manager (software), Web UI, VIGI VMS, and VIGI Cloud VMS. Operating Temperature: -30°C to 60°C (-22°F to 140°F). Material: Metal housing.
